EXPERIMENT COVERAGE • Characteristics and working principles of a single phase induction motor • Characteristics and working principles of a three phase induction motor • Characteristics and working principles of a three phase slip ring motor • Characteristics and working principles of a three phase synchronous motor • Implementing correct wiring connections for three phase and single phase electrical motor operation • Using Thermal overload relay as a protection device • Measuring the voltage/current of electrical motor set • Using applicable motor starter circuits to control its operation • Start/Stop motor control • Star(Wye) – Delta wiring connection of a 3 phase induction motor • Motor speed measurement and testing • Familiarization and operation of a three phase synchronous motor / machine • Using the 3 phase synchronous machine as a voltage generator • Troubleshooting techniques and approach • Power characteristics of AC motors SINGLE PHASE CAPACITOR START & RUN INDUC. MOTOR- ITEM: 1P-AC-MTR-03 • Input Voltage:240VAC • Speed: approx. 1400 rpm • Power: approx. 550W • Connection: 6 x 4mm safety sockets THREE PHASE SQUIRREL CAGE INDUCUCTION MOTOR - ITEM: 3P-AC-MTR-02 • Operating Voltage: ▪ Star (415VAC), Delta(240VAC) • Speed: approx. 1400 rpm • Power: 180W • Connection: 6 x 4mm safety sockets THREE PHASE SLIP RING ASYNCHRONOUS MOTOR - ITEM: 3P-AC-MTR-04 • Operating Voltage: ▪ Star(415VAC), Delta(240VAC) • Speed: approx. 1400 rpm • Power: 100W • Connection: 9 x 4mm safety sockets THREE PHASE SYNCHRONOUS MOTOR - ITEM: 3P-SYN- AC-MTR-03 • Operating Voltage: ▪ Star(415VAC), Delta(240VAC) • Speed: approx. 1500 rpm • Power: Motor 90W, Generator 170W • Connection: 8 x 4mm safety sockets THREE PHASE POWER SUPPLY CONTROL UNIT - ITEM: PSC-3P-01 • Protection device control electrical power of the training system, provide overload and short circuit protection. • Input Voltage: 415VAC 50Hz • ON/OFF Main Switch • RCCB (In 25A/ IΔn 30mA) • Resettable fuse protection • Pilot lamp indicator (L1/L2/L3) • BS13 switch socket X 2 • 5 pin CEE socket (16A) X 1 • Connection: 10 x 4mm safety sockets VARIABLE THREE PHASE AC POWER SUPPLY UNIT - ITEM: PSU-3P-01 • Input voltage: 415VAC 50Hz • Adjustable output: 0 ~ 450VAC (3A max) • ON/OFF Main Switch • Resettable fuse protection (6A) • Pilot lamp indicator (L1/L2/L3) • Digital indicator for AC voltage • Connection: 10 x 4mm safety sockets AC MEASUREMENT UNIT - ITEM: PM-03 • Input voltage: 240VAC 50Hz • AC Voltmeter X 2 • Measurement range: AC 500V • Panel Size: 78mm x 42mm • AC Ammeter X 2 • Measurement range: AC 5A • Panel Size: 78mm x 42mm • Connection: 4mm safety sockets LAMP MODULE - ITEM: LAMP-LD-01 • Pilot Lamp (240V), Red X 2 • Pilot Lamp (240V), Green X 2 • Lamp bulb with socket X 1 • Connection: 4mm safety sockets SWITCH MODULE - ITEM: SWM-01 • Push Button (NO) X 2 • Push Button (NC) X 2 • Emergency Button (NC) X 1 • Toggle Switch (2 pole) X 1 • Selector Switch (3 Pole) X 1 ANALOG TIMER MODULE - ITEM: TIM-01 • Input voltage: 240VAC/24VDC • Adjustable time setting range: 0.05 sec to 100 hour • Contact type: Time limit DPDT • Contact rating: 250VAC max 5A • Insulation resistance: Min. 100MΩ • Dielectric strength: AC 2000V 50/60Hz • Connection: 4mm safety sockets SWITCH MODULE - ITEM: SWM-01 • Push Button (NO) X 2 • Push Button (NC) X 2 • Emergency Button (NC) X 1 • Toggle Switch (2 pole) X 1 • Selector Switch (3 Pole) X 1 ANALOG TIMER MODULE - ITEM: TIM-01 • Input voltage: 240VAC/24VDC • Adjustable time setting range: 0.05 sec to 100 hour • Contact type: Time limit DPDT • Contact rating: 250VAC max 5A • Insulation resistance: Min. 100MΩ • Dielectric strength: AC 2000V 50/60Hz • Connection: 4mm safety sockets THREE PHASE CONTACTOR MODULE - ITEM: MC-02 • Magnetic Contactor X 2 • 3 pole contactor with 1NC/1NOaux. contact • Maximum voltage: 690VAC • Power: 4kW (380/440V) • Current: 9A (380/440V) • Coil voltage: 240VAC • Connection: 4mm safety sockets CONTACTOR AND OVERLOAD RELAY MODULE - ITEM: COR-01 • Magnetic Contactor X 1 • 3 pole contactor with 1NC/1NO aux. contact • Maximum voltage: 690VAC • Power: 4kW (380/440V) • Current: 9A (380/440V) • Coil voltage: 240VAC • Thermal Overload Relay X 1 • Maximum voltage: 690VAC • Trip class: 10A • Current setting range: 1 ~ 1.6A • Connection: 4mm safety sockets SWITCHABLE RESISTOR BANK MODULE - ITEM: SRB- 3P-01 • 0/40/80 ohm (100W) X 3 • Selector switch for 3 steps variable per phase • Applicable for AC Motor as starting resistor • Connection: 4mm safety socket DIGITAL ELECTRICAL METER MODULE • Input voltage: 240VAC 50Hz • Current rating: 5A Max. • Voltage rating: 20 ~ 300V (Phase voltage), 500V (Line voltage) • Measurement: PF, Hz, kW, kVAR, kVA, kWH, kVARH • Connection: 4mm safety sockets DIGITAL TACHOMETER • Photo Tach: ▪ 0.01RPM(2.5~999.99RPM) ▪ 0.1RPM(1,000~9,999.9RPM) ▪ 1RPM(over 10,000RPM) • Contact Tach: ▪ 0.01RPM(0.5~999.99RPM) ▪ 0.1RPM(1,000~9,999.9RPM) ▪ 1RPM(over 10,000RPM) BENCH TOP MOUNTING FRAME - ITEM: FRAME-02 • Aluminium/Metal construction • 4mm safety connecting leads set • 2 or 3 layer • Mounting of the training modules • Dimension 1050mm (L) 4MM SAFETY CONNECTING LEADS - ITEM: 4MM-SCL • 4mm safety connecting leads set DC POWER SUPPLY EXCITED UNIT - ITEM: TIM-01 • Input voltage: 240VAC 50Hz • Adjustable output: 0 ~ 30VDC (3A max) • ON/OFF Power Switch • Fuse protection • Digital indicator for DC voltage and DC current • Connection: 3 x 4mm safety MANUAL & ACCESSORIES • Operation / User Manual x 1 • Lab Experiment Manual (with answer) x 1
